Stainless Steel Linear Shower Drains

Linear shower channels

Stainless Steel Linear Shower Drains

FLOZN linear shower drains combine a slim stainless steel channel with a push-fit outlet for walk-in showers, wet rooms, balconies and tiled floors. Choose a tile-insert channel that disappears into the floor, or a square-pattern grate for a crisp architectural line.

Standard lengths run from 300 mm to 1200 mm with a 50 mm push-fit outlet and a 70–80 mm channel width. Odour traps are available.

AISI 316 / 304300 – 1200 mmOdour trap option
FLOZN FZ-4R-SXXXX Linear Shower Drain – Recessed Tile Insert
FZ-4R-SXXXX

Linear Shower Drain – Recessed Tile Insert

Shower channel drain with push-fit outlet; stainless steel body with drop-in tile insert tray.

Material
AISI 316 stainless steel (AISI 304 optional)
Finish
Mirror (standard) / Matte (optional)
Features
Recessed / tile insert. Odour trap (optional)
Applications
Finished areas, bathrooms, balconies & tiled areas
ModelABCDEF
FZ-4R-S12081200119026505070
FZ-4R-S090890089026505070
FZ-4R-S060860059026505070
FZ-4R-S030830029026505070

All dimensions in mm. Other sizes and finishes on request.

FLOZN FZ-4G-SXXXX Linear Shower Drain – Square Grate
FZ-4G-SXXXX

Linear Shower Drain – Square Grate

Shower channel drain with push-fit outlet; stainless steel body with removable grating and inbuilt trap.

Material
AISI 316 stainless steel (AISI 304 optional)
Finish
Matte (standard) / Mirror (optional)
Features
Square-pattern removable grate. Odour trap (optional)
Applications
Finished areas, bathrooms, kitchens & tiled areas
ModelABCDEF
FZ-4G-S12081200119625405080
FZ-4G-S1008100099625405080
FZ-4G-S090890089625405080
FZ-4G-S080880079625405080
FZ-4G-S060860059625405080
FZ-4G-S045845044625405080
FZ-4G-S030830029625405080

All dimensions in mm. Other sizes and finishes on request.

FLOZN FZ-9-SG Linear Shower Drain – Square Grate (Push-Fit)
FZ-9-SG

Linear Shower Drain – Square Grate (Push-Fit)

Shower channel drain with push-fit outlet; stainless steel body with removable grating and inbuilt trap.

Material
AISI 316 stainless steel (AISI 304 optional)
Finish
Matte (standard)
Features
Removable square grate. Odour trap (optional)
Applications
Finished areas, bathrooms, kitchens & tiled areas
ModelABCDEF
FZ-91200-SG1200119625405080
FZ-90800-SG80079625405080
FZ-90600-SG60059625405080
FZ-90450-SG45044625405080
FZ-90300-SG30029625405080

All dimensions in mm. Other sizes and finishes on request.

Why FLOZN

Engineered drainage you can specify with confidence

Marine-grade steelAISI 316 stainless steel as standard, AISI 304 on request.
Full submittalsDatasheets, dimension tables and samples for consultants and contractors.
Registered brandFLOZN – Registered Trademark # 7155330, Class 6.
FAQ

Frequently asked questions

What lengths are available for FLOZN linear shower drains?

Standard lengths are 300, 450, 600, 800/900 and 1200 mm depending on the model. Special lengths can be made on request.

What is the difference between FZ-4R and FZ-4G?

FZ-4R is a recessed tile-insert channel – the tray holds a strip of floor tile. FZ-4G and FZ-9-SG have a removable stainless steel square-pattern grate.

What outlet size do the channels use?

Channels have a 50 mm push-fit outlet. FZ-4G and FZ-9-SG have a 25 mm channel depth and 40 mm outlet height; the recessed FZ-4R has a 26 mm channel depth and 50 mm outlet height.

Can I get a trap with the linear drain?

Yes, an odour trap is available for FLOZN linear drains; FZ-4G and FZ-9-SG channels include an inbuilt trap.
